1000L Double Copper Pot Whiskey Alcohol Distillation Equipment

1000L Double Pot Copper Whiskey Stripping Still
Can make low proof alcohol or stripping whisky.
suit for whisky.

Quantity:
  • DYE-Pot still
  • DYE
  • HS: 8438400000

We can customize stills according to your needs, with any size boiler or column diameter. The columns & condensers can be made with copper or stainless steel according to your needs.

The Picture above is of our Jacketed, Steam Heated, and 1000L traditional type whisky Still.  These 1000L Stills can be heated by Low Pressure Steam Boiler  or by our optional Electric Self Contained oil bath Heating System. This type of still is great for stripping, Rum, Brandy, Moonshine and Whiskey.

This Still comes standard with:

Pot Materials: Stainless steel 304 with copper pot

Agitator with long heavy blades for mash cooking

Italy brand gear box, NEMA standard for North American Market

Explosion proof motor, can be CE, UL, CSA approved

Low pressure steam jacketed heating or oil (water) bath electric heating system

Large glass manway

Variety of customized copper whisky head

Large size Tube and Shell copper Condenser

Copper spirits safe

Coil type condenser

Spirits storage tank

Pressure Relief Valve and pressure gauge for inner boiler and jacket

PU insulation

Tri Clamp Butterfly Valve on the drain

CIP in the pot, whisky head and condenser

Stainless steel or copper parrot

Bolt to the Floor Stainless Table Stand or Stainless Column Stand for the Condenser, You Pick.

Mirror Polish Inside

Swirl pattern outside, satin finish outside or mirror polish

CIP pump and CIP manifold is optional


DAEYOO PED English         2017CE           ISO 2017


Pot

Material: Stainless Steel 304, Red Copper T2
Type: 1. single layer ; 2. with heating jacket only; 3. with heating jacket & PU insulation.
Accessories: thermometer, thermowell, pressure guage, pressure relief valve, inlet, outlet, breath valve, reflux hole, glass man hole, CIP ball, etc.

1 pots for referance

Agitator

Material: Stainless Steel 304, Union Connection, easy to installtion.
Voltage: 208V/ 220V/ 240V/ 380V/415V/ 460V etc ( can supply voltage according to customer request,
Exproof motor with CE/ UL / CSA certificate.  2 Agitator


Goose Neck / Vapor Chamber

Material: Stainless Steel / Red Copper
Have different shape for opition.

3 Goose neck

Gin Basket/ Botanical Basket

Enhance flavor and extended the range of your system.
For making Gin, Schnapps, etc.
Material: Stainless Steel/ Red Copper
Inside with removable filter basket, have different shape for opition.

4 gin basket扣_看图王


Distillation Column

We can tailor the height and plate number for your specific application.
The max height of column can reach 2000mm, up to 10 plates within a pair of flange.
For 70-90%abv: 4~6 plates; for 88-95%abv: 6~20 plates

5 Column specs 扣


Bubble Tray / Bubble Cap

The bubble tray intergrated within a tightly embedded inner shell, to avoid welding scar around the column.
Bubble caps and screw are made of red copper, the screw with a no dead corner design, can 100% meet sanitary stand.

The bubble cap have 6 size: DN26/ DN38/ DN45/ DN52/ DN65/ DN76

 5 Bubble caps and trays 扣


Dephlegmator

A chilling apparatus (condenser) at the top of the reflux column.
It's comprised of a bank of tubes with cold water running through them. This increase reflux, and the purity o f the distillate.
Material: Red Copper / Stainless Steel 304L
Structual tube type heat exchanger, with cooling water inlet and outlet
with a sight glass (optional) and thermometer in the top.

6


Condenser

A heat exchanger in which hot vapors are cooled and condensed into liquid.
Material: Red Copper / Stainless Steel 304
Structural tube type heat exchanger; with cooling water inlet and outlet.
With a thermometer.

for stainless steel condenser, the surface can finished as scaled.

13 Condenser 扣


Parrot Outlet

Material: Stainless Steel 304/ Glass/ Red Copper
Can supply different shape of spirit safety according to customer's request.

11 Parrots 扣

CIP Pump & Pipe Fitting

All stainless steel 304 pipe fitting with a Ex-proof centrifugal pump (UL/ CSA/ CE )
Have Hand Valve and Automatic Valve for opition.

7 CIP pumps and pipe fittings 扣

Support leg

All support are made of stainless steel 304
Can shaped as customers request.

5 column base 扣


Alcohol Collecting Tank

Used for storage spirit of head, heart and tails.
Can do as different shape.
Structure: Single layer

12 Collection tanks after distilling equipment 扣






7DYE-I Whisky still

Working Capacity: 250L

All copper inner pot with SUS304 jacket & PU foam insulation

Electric oil bath heating with control box

Power consumption: 3*7kw electric heater ( or 25kg/h steam heating)

Agitator: 0.75kw motor, explosion proof with UL & CSA & CE approved

Copper helemt: ball shape (also have other shape for choice)

4 Plates Copper column:  16 inch / 400mm

Copper dephlegmator : shell and tube type

Copper condenser : shell and tube type

Copper parrot with glass proof

SUS304 CIP system: CIP ball & no-return ball, CIP pipe, CIP pump

SUS304 alcohol collecting tank: 300L

Bypass system: from pot to condenser directly

Price: 25000USD-35000USD


01

DYE-II Gin still

Working Capacity: 300L

All copper inner pot with SUS304 jacket & PU foam insulation

Electric oil bath heating with control box

Power consumption: 3*8kw electric heater ( or 30kg/h steam heating)

Agitator: 0.75kw motor, explosion proof with UL & CSA & CE approved

Copper helemt: cone shape (also have other shape for choice)

4 Plates Copper column:  8 inch / 219mm

Copper Dephlegmator : shell and tube type

SUS304 Gin basket: inner with copper basket

SUS304 Condenser : shell and tube type

SUS304 Parrot with glass proof

SUS304 CIP system: CIP ball & no-return ball, CIP pipe, CIP pump

SUS304 alcohol collecting tank: 300L

Bypass system: from pot to condenser / from pot to gin basket to condenser / from pot to column to condenser

Price: 23000-33000USD.


1

DYE-III Multi-Purpose still

Working Capacity: 1000L

Upper copper inner pot with SUS304 jacket & PU foam insulation

Steam heating without control box

Power consumption:  100kg/h steam heating  (or 6*10kw electric heaters)

Agitator: 1.1kw motor, explosion proof with UL & CSA & CE approved

Copper helemt: mushroom shape (also have other shape for choice)

Glass Gin basket: inner with copper basket

4 Plates + 16 Plates Copper column:  14 inch / 350mm

SUS304 Dephlegmator : shell and tube type

SUS304 Condenser : shell and tube type

SUS304 Parrot with glass proof

SUS304 CIP system: CIP ball & no-return ball, CIP pipe, CIP pump

Bypass system: from pot to condenser / from pot to gin basket to condenser / from pot to column to condenser. etc.

Price: 60000USD-85000USD.


01

DYE-IV Vodka still

Working Capacity: 1000L

Upper copper inner pot with SUS304 jacket & PU foam insulation

Steam heating without control box

Power consumption:  100kg/h steam heating  (or 6*10kw electric heaters)

Agitator: 1.1kw motor, explosion proof with UL & CSA & CE approved

Copper helemt: mushroom shape (also have other shape for choice)

4 Plates + 12 Plates Copper column:  14 inch / 350mm

Copper Dephlegmator : shell and tube type

Copper Catalyst : filled with copper material

SUS304 Condenser : shell and tube type

SUS304 Parrot with glass proof

SUS304 CIP system: CIP ball & no-return ball, CIP pipe, CIP pump

SUS304 Alcohol storage tank for hearts, heads & tails

Bypass system: from pot to condenser / from pot to high column to condenser / from pot to short column to condenser.

Price: 60000USD-85000USD.
